60
Operation via electric push-button
When operating the machine, the tipping device can be moved by means of a push-button and
two-hand selector switches UP and DOWN.
In this case, the two-hand selector switch and the "UP" button must be pressed in order to
move the tipping device upward.
In order to bring the tipping device back to the lower position, the two-hand selector switch
and the "DOWN" button must be pressed.
As soon as the selector switch or one of the buttons is released, the tipping device stops in the
respective position.
12.1 Lid and tipping device variations
Rigidly mounted tipping device on the front side of a SPB 20 SEL. Tipping device equipped
with lid opener and foldable tipper chute. Operation via hand valve and two-hand selector
switch, or electric push-button. The tipping device can receive bins via the laterally fitted pins
(boss lift system). Use only approved and suitable bins.
