5
3.3.1 Rating plate
All machines leaving the factory are marked with a nameplate as shown in the following fi-
gure. The nameplate gives you an overview of the most important data of the machine and
contains the serial number that determines the machine.
Power supply:
Supply voltage: 400 / 3×230
V AC
Frequency: 50
Hz
Protection, type K, 3-pole 16/25
A
Main drive:
Voltage (~ 3 Ph.): 400 / 3 x 230
V AC
Power: 5,5 / 7,5
kW
Control system:
Control voltage: 230 or 24 / 24
V AC / V DC
