85
• Close the cover above the power pack and lock the locks with the triangular key
Power unit and electric switch box - installation in the upper part of the container
Power pack fitted into the top of the container part of the portable compactor. This variant can
be selected for the following reasons:
• To reduce the filling height at the front of the portable compactor
• In case of a wall-connected chute or if feeding is done via conveyor belt or a separator, to
have easy access to the hydraulic and electrical components which are otherwise covered
• Tipping device – loading shovel
When working on the hydraulic and electrical components use only approved ladders in
accordance with the relevant DIN regulation.
screws on the cover above the power pack open the cover
