MEP S.p.A.
1--6 Use and maintenance manual DM 8
ELECTROPU MP MOTOR
Single phase; Frequency 60 Hz.
Voltage (Volts) Absorption (Amps) Power (HP) rpm Delivery rate
lt/min
Head (mt.)
208 0.22 0.1 3380 11 1.5
240 0.2 0.1 3380 11 1.5
575 0.16 0.1 3380 11 1.5
Protection rating IP 55.
Conforming to CEI norms, publication: IEC 34 of 01/07/1985.
CUTTING CAPACITY
Section
Ø
lxl
bxh
0˚ 210 mm = 8.27 in. 200 mm = 7.87 in. 270x200 mm = 10.63x7.87 in.
45˚ left 180 mm = 7.09 in. 180 mm = 7.09 in. 180x190 mm = 7.09x7.48 in.
60˚ left 100 mm = 3.94 in. 90 mm = 3.54 in. 120x90 mm = 4.72x3.54 in.
45˚ right 130 mm = 5.12 in. 130 mm = 5.12 in. 120x150 mm = 4. 72x5.90 in.
PACKED WEIGHT
Wooden cage and pallet Kg 70
Wooden pallet Kg 20
1700 mm
1000 mm
1900 mm
66.93 in.
39.37 in.
74.80 in.
