3. Rotate the Upper Line knob to select the day pattern type.
4. Using the Lower Line knob, select the day pattern for the
selected schedule.
5. Rotate the Upper Line knob to select the setting for the selected
day pattern.
6. Using the Lower Line knob, set the day pattern settings.
Water day patterns available: “Automated by WeatherTRAK,”
“Odd/Even,” “Interval” and “Days of Week.”
Programs
The PROGRAM feature will allow you to modify any of your
station-specific settings.
To set a station’s program:
1. Turn the Function Selector knob to PROGRAM.
2. Using the Lower Line knob select the station to program.
3. Rotate the Upper Line knob to select the program mode.
4. Using the Lower Line knob, select the program mode.
5. Automatic Mode: Using the Upper and Lower Line knobs, select
a schedule (A or B), enter the landscape and irrigation system
parameters you gathered in the “Site Data Gathering” section on
page 95.
6. “User Programmed--With ET” or “User Programmed--NO ET”
mode: Using the Upper and Lower Line knobs, enter the cycle
runtime, number of cycles, soak time and day pattern for the
station.
7. Refer to chapter three of this manual for more information.
Quick Reference Guide84
