Hypertherm Powermax 65 Service Manual

powermax 65/85 Service Manual 1-1
Section 1
SPECIFICATIONS
In this section:
Safety information ...................................................................................................................................................................................1-2
System description ................................................................................................................................................................................. 1-2
Where to find information .....................................................................................................................................................................1-3
Power supply dimensions .....................................................................................................................................................................1-4
Component weights ............................................................................................................................................................................... 1-5
Powermax65 power supply ratings ....................................................................................................................................................1-6
Powermax85 power supply ratings ....................................................................................................................................................1-8
Duramax 75° hand torch dimensions .............................................................................................................................................. 1-10
Duramax 15° hand torch dimensions .............................................................................................................................................. 1-10
Duramax 180° full-length machine torch dimensions .................................................................................................................. 1-11
Duramax 180° mini machine torch dimensions ............................................................................................................................. 1-11
Powermax65 cutting specifications ................................................................................................................................................. 1-12
Powermax85 cutting specifications ................................................................................................................................................. 1-13
Symbols and markings ........................................................................................................................................................................ 1-14
IEC symbols .......................................................................................................................................................................................... 1-15

Hypertherm Powermax 65 Specifications

General

Open Circuit Voltage (OCV)	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Maximum Cut Capacity (Mild Steel)	1" (25 mm)
Input Voltage	200-600 V, 1/3-PH, 50/60 Hz
Output Current	20 – 65 A
Duty Cycle	50% @ 65 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Torch Lead Length	25 ft (7.6 m)
Maximum Cut Capacity (Aluminum)	5/8" (16 mm)
Severance Cut Capacity (Mild Steel)	1-1/4" (32 mm)
Maximum Severance Thickness	1-1/4 in (32 mm)
Gas Type	Air/Nitrogen
Torch Options	Hand Torch, Mechanized Torch
