General| Open Circuit Voltage (OCV) | 300 VDC |
|---|---|
| Gas Supply | Clean, dry, oil-free air or nitrogen |
| Maximum Cut Capacity (Mild Steel) | 1" (25 mm) |
| Input Voltage | 200-600 V, 1/3-PH, 50/60 Hz |
| Output Current | 20 – 65 A |
| Duty Cycle | 50% @ 65 A |
| Recommended Gas Inlet Flow Rate/Pressure | 6.7 scfm @ 85 psi |
| Torch Lead Length | 25 ft (7.6 m) |
| Maximum Cut Capacity (Aluminum) | 5/8" (16 mm) |
| Severance Cut Capacity (Mild Steel) | 1-1/4" (32 mm) |
| Maximum Severance Thickness | 1-1/4 in (32 mm) |
| Gas Type | Air/Nitrogen |
| Torch Options | Hand Torch, Mechanized Torch |
