Hypertherm Powermax 65 Service Manual

Power SuPPly SetuP
2-6 powermax 65/85 Service Manual
Power connection for the Powermax65
The Powermax65 CSA model is a universal power supply that can configure itself to operate with AC voltages from
200to 600, 1- or 3-phase. The CE model is 380/400 V, 3-phase only. The rated output is 25 – 65A, 139 VDC.
CSA model Single-phase Three-phase
Input voltage 200 – 208 230 – 240 480 200 – 208 230 – 240 400 480 600
Input current at
9.0kw output
52 44 22 32 27 15 13 13
Input current
during arc stretch
74 74 38 45 45 27 23 23
Fuse (slow-blow) 80 80 40 50 50 30 25 25
CE model Three-phase
Input voltage 380/400
Input current at
9.0kw output
15.5/15
Input current
during arc stretch
27
Fuse (slow-blow) 30

Hypertherm Powermax 65 Specifications

General

Open Circuit Voltage (OCV)	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Maximum Cut Capacity (Mild Steel)	1" (25 mm)
Input Voltage	200-600 V, 1/3-PH, 50/60 Hz
Output Current	20 – 65 A
Duty Cycle	50% @ 65 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Torch Lead Length	25 ft (7.6 m)
Maximum Cut Capacity (Aluminum)	5/8" (16 mm)
Severance Cut Capacity (Mild Steel)	1-1/4" (32 mm)
Maximum Severance Thickness	1-1/4 in (32 mm)
Gas Type	Air/Nitrogen
Torch Options	Hand Torch, Mechanized Torch
