Hypertherm Powermax 65 Service Manual

TroubleshooTing and sysTem TesTs
powermax 65/85 Service Manual 5-53
Test 10 – Pressure sensor
Symptom: The pressure sensor reading doesn’t agree with known pressures.
Note: Wear proper personal protective equipment (PPE) before testing powered equipment.
1. Remove the white cover on the plug at J5 for CSA units or J7 for CE units.
2. Turn the machine on.
3. Measure power to the sensor between Pin 2 and Pin 3.
If not 5.0 (±5%) perform the Flyback Circuit test above.
4. Display the service screen (refer to page 5-21 Displaying the service screen). Enable the gas test by moving the
cursor to the “G” field and turning the adjustment knob to display “1” in the field. To turn off the gas test, turn the
adjustment knob to display “0” in the field.
Note the flowing gas pressure in the “P” field to the right of the slash.
5. Measure VDC between Pin 2 (-) and Pin 1 (+)
The value should be 0.0463 times the pressure, for example (68 PSI * .0463 VDC/PSI = 3.148 VDC).
If the voltage measurement is within ±10% of the correct value and you have a pressure warning or fault:
a. Test with a known working DSP board.
b. If the measured voltage is correct, replace the DSP board.
c. If the measured voltage is not correct, replace the pressure sensor.

Hypertherm Powermax 65 Specifications

General

Open Circuit Voltage (OCV)	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Maximum Cut Capacity (Mild Steel)	1" (25 mm)
Input Voltage	200-600 V, 1/3-PH, 50/60 Hz
Output Current	20 – 65 A
Duty Cycle	50% @ 65 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Torch Lead Length	25 ft (7.6 m)
Maximum Cut Capacity (Aluminum)	5/8" (16 mm)
Severance Cut Capacity (Mild Steel)	1-1/4" (32 mm)
Maximum Severance Thickness	1-1/4 in (32 mm)
Gas Type	Air/Nitrogen
Torch Options	Hand Torch, Mechanized Torch
