Hypertherm Powermax 65 Service Manual

SpecificationS
1-8 powermax 65/85 Service Manual
Powermax85 power supply ratings
Rated open-circuit voltage (U
0
)
CSA, single-phase, 3-phase
CE, 3-phase
CSA
CE
305 VDC
270 VDC
Output characteristic
1
Drooping
Rated output current (I
2
) 25 – 85 A
Rated output voltage (U
2
) 143 VDC
Duty cycle at 40° C (104° F)
(See data plate on power supply
for more information on duty
cycle.)
CSA
CE
60% @ 85 A, 230 – 600 V, 3 PH
60% @ 85 A, 480 V, 1 PH
50% @ 85 A, 240 V, 1 PH
50% @ 85 A 200 – 208 V, 3 PH
40% @ 85 A 200 – 208 V, 1 PH
100% @ 66 A, 230 – 600 V, 1/3 PH
60% @ 85 A, 380/400 V, 3 PH
100% @ 66 A, 380/400 V, 3 PH
Operating temperature 14° to 104° F (-10° to 40° C)
Storage temperature -13° to 131° F (-25° to 55° C)
Power factor
200 – 480 V CSA, 1-phase
200 – 600 V CSA, 3-phase
380/400 V CE, 3-phase
0.99 – 0.96
0.94 – 0.76
0.94
R
sce
– Short Circuit Ratio (CE models only) U
1
– Volts AC rms, 3PH R
sce
400 VAC 225.7
EMC classification CISPR 11 (CE models only)
4
Class A
Input voltage (U
1
)/ Input
current (I
1
) at rated output
(U
2MAX
, I
2 MAX
) (See Section 2
Power Supply Setup for more
information.)
CSA
CE
2,3
200/208/240/480 V, 1 PH, 50/60 Hz
70/68/58/29 A
200/208/240/480/600 V, 3 PH, 50/60 Hz
42/40/35/18/17 A
380/400 V, 3 PH, 50/60 Hz
20.5/19.5 A
Gas type Air Nitrogen
Gas quality Clean, dry, oil-free per
ISO 8573-1 Class 1.2.2
99.95% pure
Recommended gas inlet flow
rate/pressure
Cutting: 400 scfh, 6.7 scfm (190 slpm) @ 85 psi (5.9 bar)
Gouging: 450 scfh, 7.5 scfm (210 slpm) @ 70 psi (4.8 bar)

Hypertherm Powermax 65 Specifications

General

Open Circuit Voltage (OCV)	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Maximum Cut Capacity (Mild Steel)	1" (25 mm)
Input Voltage	200-600 V, 1/3-PH, 50/60 Hz
Output Current	20 – 65 A
Duty Cycle	50% @ 65 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Torch Lead Length	25 ft (7.6 m)
Maximum Cut Capacity (Aluminum)	5/8" (16 mm)
Severance Cut Capacity (Mild Steel)	1-1/4" (32 mm)
Maximum Severance Thickness	1-1/4 in (32 mm)
Gas Type	Air/Nitrogen
Torch Options	Hand Torch, Mechanized Torch
