Hypertherm Powermax 65 Service Manual

Torch SeTup
powermax 65/85 Service Manual 3-45
85A Unshielded Air flow rate - slpm/scfh
Stainless Steel
Hot 190 / 400
Cold 235 / 500
Metric
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce Delay
Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
2
2.0
5.0 250
0.1
8550 117 11300 116
3 7000 118 9660 117
4 0.2 5600 118 7800 118
6
0.5
3400 120 4570 121
8 2250 121 2970 122
10
6.0 300
0.5 1430 123 1840 124
12 0.7 1000 129 1340 128
16
Edge Start
650 134 730 133
20 360 138 570 137
English
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce Delay
Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
in in % seconds ipm Volts ipm Volts
14GA
0.08
0.20 250
0.1 340 117 452 116
10GA
0.2
250 118 352 118
3/16 in 180 119 249 119
1/4 in
0.5
120 120 160 121
3/8 in 60 122 77 123
1/2 in 0.24 300 0.6 35 131 46 129
5/8 in
Edge Start
26 134 29 133
3/4 in 17 137 24 136

Hypertherm Powermax 65 Specifications

General

Open Circuit Voltage (OCV)	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Maximum Cut Capacity (Mild Steel)	1" (25 mm)
Input Voltage	200-600 V, 1/3-PH, 50/60 Hz
Output Current	20 – 65 A
Duty Cycle	50% @ 65 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Torch Lead Length	25 ft (7.6 m)
Maximum Cut Capacity (Aluminum)	5/8" (16 mm)
Severance Cut Capacity (Mild Steel)	1-1/4" (32 mm)
Maximum Severance Thickness	1-1/4 in (32 mm)
Gas Type	Air/Nitrogen
Torch Options	Hand Torch, Mechanized Torch
