142 Powermax30 XP Service Manual 808150 Revision 0
6 – Power Supply Component Replacement
Figure 75
6
7
5
4
3
2
1
1
Air fitting (CSA) or air fitting adapter (CE/CCC)
2
Air filter/regulator
3
Drain hose
4
Gas supply hose
5
Red and black pressure switch wires
6
Pressure switch
7
Ground wire clip on the “T” fitting
