Hypertherm Powermax30 XP Service Manual

Powermax30 XP Service Manual 808150 Revision 0 17
Section 1
Specifications
Safety information
Before operating any Hypertherm equipment, read the separate Safety and Compliance Manual (80669C) included with
your product for important safety information.
System description
The Powermax30 XP is a highly portable, 30 A, handheld plasma cutting system appropriate for a wide range of
applications. It uses air or nitrogen to cut electrically conductive metals, such as mild steel, stainless steel, or aluminum.
With it you can cut thicknesses up to 15 mm (5/8 inches) and pierce thicknesses up to 6 mm (1/4 inch).
The Powermax30 XP ships in several different configurations, based on region. Typically all configurations include:
 1 complete set of general-purpose consumables (preinstalled on the Duramax
™
LT hand torch) for standard cutting:
 1 electrode
 1 swirl ring
 1 nozzle
 1 retaining cap
 1 shield
 1 extra general-purpose nozzle
 1 extra electrode
 FineCut
®
consumables for detailed cutting:
 1 FineCut nozzle
 1 FineCut deflector
 1 region-specific air fitting:
 Industrial interchange quick-disconnect nipple with 1/4 NPT threads (CSA models)
 British Pipe Thread adapter G-1/4 BSPP with 1/4 NPT threads (CE and CCC models)
