Hypertherm Powermax30 XP Service Manual

Powermax30 XP Service Manual 808150 Revision 0 31
Section 3
Torch Setup
Introduction
The Powermax30 XP includes the Duramax LT hand torch. This section explains how to set up and operate your torch. To
achieve optimal consumable life and cut quality, follow the instructions in this manual.
Hand torch components
1
2
3
4
5
6
1
Handle
2
Shield (shown) or deflector
3
Retaining cap
4
Safety catch
5
Trigger (red)
6
Screws (5)
