154 Powermax30 XP Service Manual 808150 Revision 0
6 – Power Supply Component Replacement
8. Disconnect the control panel ribbon cable from the power board by folding the latches back.
In Figure 85, the center panel is hidden in the image on the left.
Figure 85
1
2
3
4
2
3
4
1
Latches
2
Control board
3
Ribbon cable
4
Power board
