2) Check list of Hoist way
• Counter weight: CWT
 Acquire adequate amount of counter weights to prevent slipping.
 Check amount of counter weights are excessive/insufficient or not
• Hoist way
 Check if there is an obstacle interfering with CAR frame and Counter weight frame.
 Check the tightness and mounting status of each bolt.
 Install the safety shelter plate at the floor door part to prevent safety accidents and product
damage.
3) Preparations for pit
• Buffer
 Check if the safety buffer is correctly installed and adequate amount of oil is inserted into oil
buffer.
• Check Projected Parts
 For safety, check and remove unnecessary projected parts.
4) Control Panel Inspection
 Check if Control Panel is placed and fixed for the worker to perform adequately, The front part
should have the gap of 1m or more with other obstacles)
 Unwrap the cover of Control Panel and check if the mounting of each part is correct.
 Check the status of the inserted connectors. (check wrong insertion, contact defect)
 Check if the connector of the power part is sufficiently tightened.
 Check if main power, motor capacity, NFB, inverter and reactor, brake resistance (WB200G/GT,
WB210GT inverter have no reactor and brake resistance), etc. are mounted according to the
specification.
 The height of Control Panel can be adjusted with a separate bracket at the bottom, so use it if
necessary.
