Hyundai Elevator WBVF - Connector Names

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
50 / 98
6.3.2 Connector Names
CN
Item
Description
Remark
CN_S1
Control panel emergency stop
Figure 6.3①
CN_S2
Pit safety line
Site connection (pit cable)
Figure 6.3②
CN_S3
Governor (for terminal block
connection)
*Note 1.
Figure 6.3③
CN_S4
Top part final limit
Site connection (hoist way cable)
Figure 6.3④
CN_S5
Bottom part final limit
Site connection (hoist way cable)
Figure 6.3⑤
CN_S6
Landing door
Site connection (interlock)
Figure 6.3⑥
CN_S7
Landing door
Site connection (interlock)
Figure 6.3⑦
CN_S8
CAR safety line
Site connection (T.CABLE)
Figure 6.3⑧
CN_S9
For electrical emergency operation
jumper
Figure 6.3⑨
CN_S11
For SAF board power
Figure 6.3⑩
CN_S12
For safety relay fuse inspection
Figure 6.3⑪
CN_S13
For safety line monitoring
Figure 6.3⑫
CN_S14
MRL external input/output signal
connection
Figure 6.3⑬
CN_S19A
Landing van signal
Site connection (T.CABLE)
Figure 6.3⑭
CN_S19B
Landing van signal
Main B'd connection
Figure 6.3⑮
CN_S22
For Door zone sensor signal
UCMP B‟d connection
Figure 6.3⑯
CN_S23
For car door & landing door s/w
signal
UCMP B‟d connection
Figure 6.3⑰
CN_S24
UCMP safety line
UCMP B‟d connection
Figure 6.3⑱
Governor site connection is performed at TBMB-1 and TBMB-2 terminal block.
