INSTALLATION MANUAL
FOR ELECTRICAL PARTS
5.2 How to Install Landing Device (Landing Control Device)
1) Landing device installation
Install the landing device main unit at certain location at the top of the CAR using the bracket.
At this time, considering the installation locations of the governor rope, Final limit switch, T-cable, etc.,
the landing device location should be decided to have no interference. [Figure 5.2]
2) Landing vane installation
① At the top of the CAR, install the landing vane to the rail on the part where the landing device main
unit is located.
② Adjust the landing vane to pass the center part of the landing device sensor.
③ Place the CAR on any floor so that the car level hatch floor level to perfectly match
④ Install the landing vane to be at the center of the sensor of the landing device.
⑤ Install the landing vane with the same method in all the floors
⑥ Check if there is any interference and if the gap between the sensor part and the landing vane is
uniform by operating the CAR through all the floors.
