6.1.2 Connector Name
CN
Item
Remark
CN1
MAIN POWER
Main board power
CN2
JTAG
JTAG connector
CN3
SCI
Control board monitoring
CN4
EzPort
Control board Download connector
CN5
OPTION BOARD
OPTION BOARD connector
CN6
GATE
GATE SIGNAL input/output
CN7
ENCODER
ENCODER BOARD connector
CN8
LOAD INPUT
LOAD input (not used)
CN9
INVERTER CURRENT SENSING
Inverter current sensing
CN10
INPUT DC-LINK SENSING
DC LINK voltage sensing
CN11
CAN1
CAR CAN communication
CN12
CAN2
HALL CAN communication
CN13
D/A Converter
D/A output
CN14
RS232
HRTS
CN15
RS-485
RS 485 communication(monitoring panel)
CN16
KEYPAD
Key-Pad(HHT) connector
CN17
INPUT
Up Slowdown switch
CN18
INPUT
Down Slowdown switch
CN19
INPUT
Landing Vane sensor
CN20
INPUT
Safety line monitoring
CN21
INPUT
Control input signal
CN22
OUTPUT
Control output signal
