INSTALLATION MANUAL
FOR ELECTRICAL PARTS
7.5 How to Set Hall Indicator
7.5.1 Indicator Installation and Floor Input
① Insert the connector coming out of the hall button into CH1 or CH4 of the indicator board
② There is a FL_SET JUMP pin in the hall indicator, and during the installation, you need to input the
floors according to the ID data of each floor.
Refer to Figure 7.2 for HIP / HIP MINI / HPI / CPI / floor input procedure!
Connect 24VDC power to the CH1 or CH4 of HIP / HPI Board
Connect the UP / DOWN Button to the CH2 or CH2B of board
Input the floors according to the ID data of each floor by seeing the
DOT-MATRIX display
Push the UP or DOWN Button during 5 sec
If you can see the alternating display 『OK』 and 『setting floor』 on
the DOT-MATRIX, the floor setting is completed
Release FL_SET(=JP3) jumper
the floor ID can be set from 1 to 96, the English display after 96 floor is special functions.
In case that by using the CAR indicator
In case of using 2 indicator on hall, one thing have to set as floor ID
HP
In case that by using the supervisor indicator
When it Applies
SUPERVISORY option
