Hyundai Elevator WBVF - Appendix B. Inverter Initial Start-Up Manual

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
72 / 98
Appendix B. Inverter Initial Start-Up Manual
Perform the drive for initial angle setting when initially starting up the synchronous
machine.
1. Synchronous Machine
Section
Item
Remark
Control
EL SPEED
Elevator Speed
MAX RPM
Motor RPM according to Elevator Speed
MAX FLOOR
Elevator Maximum Floors
FWD DIRECTION
Elevator Driving Direction
Motor
INVERTER SEL
Inverter Capacity
MOTOR SELECT
Motor Selection
KNOW ANGLE
Status of Initial Angle Setting
U Angle
Initial Angle
Factory
SINCOS THETA
Status of inputting SIN-COS Encoder Max/Min Value
SIN MAX
SIN-COS Encoder SIN MAX Value
SIN MIN
SIN-COS Encoder SIN MIN Value
COS MAX
SIN-COS Encoder COS MAX Value
COS MIN
SIN-COS Encoder COS MIN Value
1) SINCOS Encoder Synchronous Machine Initial Angle Setting
① 2. PROGRAM > 3. MOTOR > 10. Know Angle : ‘0’ Setting.
② 2. PROGRAM > 4. FACTORY > 13. SINCOS THETA : ‘OFF’ Setting.
③ Make Inspection Drive Mode and the Press Inspection UP Button until motor around 5 times.
④ 2. PROGRAM > 4. FACTORY > 14. SINMAX : Normal Value 3500~4095
2. PROGRAM > 4. FACTORY > 15. SINMIN : Normal Value 100~500
2. PROGRAM > 4. FACTORY > 16. COSMAX : Normal Value 3500~4095
2. PROGRAM > 4. FACTORY > 17. COSMIN : Normal Value 100~500
(When SINMAX, COSMAX, SINMIN, COSMIN value are not property , Pleas See‟ „2) SINCOS
Encoder Synchronous Machine Trouble Shooting‟ and then Try again to ②, ③.
⑤ Make Inspection Drive Mode and the Press Inspection UP Button until motor around 5 times.
⑥ Change Know Angle value to 1 by HHT and then check the
2. PROGRAM > 3. MOTOR > 11. U ANGLE Value was changed
