INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Safety Information
IMPORTANT! READ SAFETY NOTE AND THIS PAGE CAREFULLY
before installation
• When it comes to Installation and Commissioning, Person passing through training course and
having a certification provided by Hyundai Elevator co., LTD. is qualified to make a procedure.
• Wear safety devices
• Check and remove unnecessary projected parts
• Check the safety shelter plate installation at the floor side door part for the operation of the car
• No one but the approved personnel is authorized to have access to elevator equipment and
devices
• Clean up and arrange the control board and elevator controller connecting
wires. Stranded wires must be twisted before works to prevent SHORT
CIRCUIT that may occur when sticking out from the terminal block.
• Check if all controllers, field terminals and cable connectors are properly
arranged and tightened or not
• Check the location of Pin No.1 to prevent COMPONENTS DAMAGE, In case
of connecting a flat cable connector. (The location of Pin No.1 is traceable by
using the arrow mark of the connector or the red line of the cable).
