INSTALLATION MANUAL
FOR ELECTRICAL PARTS
4.3 How to Connect Hoist Way Cable Harness
• Preparation and Verification Work
Check the number of floors or CAR marking to see if the cable harness specification precisely
matches the site.
Check if there are sufficient cable ties to fix the harness in each floor hanger case.
Check if a bracket is prepared to fix on the wall of the highest part of the hoist way, and anchor
or hill tee for fixing should be prepared.
Prepare other basic tools, etc. (Knife, nipper, driver, tape measure, long nose, etc.)
When hoist way is narrow, Use the harness fixing bracket to fixing harness cable.
① Arrange the prepared cable harness to prevent tangling, put them on the top of the CAR, and
transport them to the highest floor.
② Check the locations of the indicators and buttons
③ Fix the bracket at the highest part of the harness location using hill tee and anchor. This should be
precisely installed at the location where cable goes down straight to the bottom.
④ Mark at 1m from the machine room floor as the bracket location.
⑤ Take out the starting part of the cable to the machine room through the hole of the cable duct.
⑥ Place the white part of the cable to be at position in article 3.
⑦ Insert all of the upper part into the duct hole through the bracket.
⑧ In the machine room, take out the cable came from the hoist way [Figure 4.2] to Control Panel
through the duct, check if the length is sufficient, and have the worker at the hoist way to completely
fix the cable using the fixing bracket.
⑨ Fix the communication line and interlock line at one fixing bracket.
⑩ At this time, also fix the top part Final limit switch cable to the fixing bracket, and connect to the
connector taken out from the switch.
