Hyundai Elevator WBVF - Inside;Outside CAR; How to Install CAR Junction Box

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
31 / 98
5. Inside/Outside CAR
WBVF system has combined door controller and CAR top BOX.
CAR peripherals should be installed as follows.
5.1 How to Install CAR Junction Box
① Install the CAR junction box at the top of the CAR as in [Figure 5.1]. Install the CAR junction box for
the worker at the hall side to be able to work manual/automatic, Light switch, E-STOP switches
within 1m. (Install the CAR J.BOX in the direction where the front part of the switches can be seen.)
② CTX board is embedded in the CAR junction box, so you have to be careful not to damage the
boards by water leakage. [Figure 2.3]
③ Connect CAR junction box and door motor and door encoder.
④ Perform the door adjustment by referring to a separate WBVF Door controller Manual.
⑤ Installation of the CAR junction box and connection of the peripheral devices
The following installation work should be performed after turning OFF the main power of Control
Panel.
CAR junction box contains the circuit boards, extra fuse, installation jumpers, etc. at ship-out, so
work with caution not to lose parts and not to damage the enclosed items during the installation.
After completing the installation of the CAR junction box, connect the peripheral devices of the CAR
with CTC board and CTX board.
[Table 5.1 CAR Junction Box Board terms]
No.
Name
Description
No.
Name
Description
1
CTC
Car Top Controller
9
2
CTX
Car Top Extension
10
3
CJB
Car Junction Box
11
4
CPI
Car Positioned
12
5
COP
Car Operating Panel
13
6
M.COP
Main COP
14
7
S.COP
Sub COP
15
CAN
Controller Area Network
8
D.COP
Disable COP
