Hyundai Elevator WBVF - Connector Names

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
48 / 98
6.2.2 Connector Names
CN
Item
Description
Remark
CN_S1
Control panel emergency stop
Figure 6.2①
CN_S2
Pit safety line
Site connection (pit cable)
Figure 6.2②
CN_S3
Governor
(for terminal block connection)
*Note 1.
Figure 6.2③
CN_S4
Up final limit
Site connection (hoist way cable)
Figure 6.2④
CN_S5
Down final limit
Site connection (hoist way cable)
Figure 6.2⑤
CN_S6
Landing door
Site connection (interlock)
Figure 6.2⑥
CN_S7
Landing door
Site connection (interlock)
Figure 6.2⑦
CN_S8
CAR safety line
Site connection (T.CABLE)
Figure 6.2⑧
CN_S9
For electrical emergency operation
jumper
Figure 6.2⑨
CN_S11
For SAF board power
Figure 6.2⑩
CN_S12
For safety relay fuse inspection
Figure 6.2⑪
CN_S13
For safety line monitoring
Figure 6.2⑫
CN_S14
MRL external input/output signal
connection
Figure 6.2⑬
CN_S19A
Landing van signal
Site connection (T.CABLE)
Figure 6.2⑭
CN_S19B
Landing van signal
Main Board connection
Figure 6.2⑮
Governor site connection is performed at TBMB-1 and TBMB-2 terminal block.
