Hyundai Elevator WBVF - Main Board Power Specification; Check Points after Supplying the Power

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
46 / 98
6.1.3 Main Board Power Specification
CN
PIN
Item
Remark
CN1
1
VCC(+5V)
Main board power
2
GND
3
-15V
4
+15V
6.1.4 Check Points after Supplying the Power
LED
Item
Remark
LED1
VCC(+5V) checking signal
ON
LED2
Watch Dog checking signal
Blinking
LED3
DC Link input checking signal
ON
LED4,LED5
CAR CAN blinking signal
Blinking
LED6,LED7
HALL CAN blinking signal
Blinking
In normal operation, LED1 and LED3are ON, and LED2, LED4, LED5, LED6, and LED7
are blinking.
