A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
38 / 98
2) Applied Boards and Buttons
Board Type
Specification
Remark
COP-30D Board
COP Control Board
COP control board
CPI
Car Position IND(CAN type)
Same as the circuit board for Hall
communication
OPB button
300Ω
Not compatible with Hall button
3) Main COP Installation and Connection
In the main COP includes 『C1 cable』,『C2 cable』,『A1 cable』, 『A2 cable』and『CN_B1』.
After installing the main COP, connect the connectors of each cable to SUB COP-30D, WCOP30, CTC
Bd, and CTX Bd.
Cable Name
Starting Point
Destination
SUB COP
CAN communication
cable (C2)
MAIN
COP-30D Board
CN_C10
SUB
COP-30D Board
CN_C10
DISABLE COP
CAN communication
cable (C1)
MAIN
COP-30D Board
CN_C6
WCOP30 Board
CN_W1
LOAD SWITCH
(A2)
MAIN
COP-30D Board
CC26
LOAD SWITCH
COP-CJB cable
(A1)
COP Panel
CN_B1
CTC Board,
CTX Board
CN_T2, CN_T13,
CN_T1,CN_T9,
CN_T22, CN_T30
4) Handicappedped COP Installation and Connection
In the Handicappedped COP, 『B2 cable』 and『C1 cable』 are taken out.
Connect 『B2 cable』 to main COP COP-30D board.
Connect 『C1 cable』 to SB2 connector taken out from C1 of the main COP DI-PBX II board.
Cable Name
Starting Point
Destination
DISABLE COP
CAN communication
cable (C1)
WCOP30 Board
CN_W1
MAIN
COP-30D Board
CN_C6
Emergency call button
cable (B2)
Emergency call
button
CAR TOP
SB2
