Hyundai Elevator WBVF - Page 39

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
39 / 98
5) Sub COP Connection
In sub COP, 『CAN communication cable: C2』 and 『Emergency call button cable: B2』 are taken out.
Connect『C2 cable』 to the main COP COP-30D board.
Connect『B2 cable』to SB2 connector taken out from CN1 of COP DI-PBX II board.
Cable Name
Starting Point
Destination
CAN communication
cable (C2)
SUB
COP-30D Board
CN_C10
MAIN
COP-30D Board
CN_C10
Emergency call button
cable (B2)
Emergency call
button
CAR TOP
SB2
