A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
13 / 98
2. Preparations for Installation
IMPORTANT! READ SAFETY NOTE AND THIS PAGE CAREFULLY
before installation
2.1 Machine Room Environment
• Machine room should have sufficient space for the work.
• Machine room should have lights for the work.
Adequate temperature for the machine room is 0℃~40℃. (For other conditions,
install heater / air conditioner.) If it is not an adequate temperature, it may affect the
lifetime of the parts.
• The location of the machine room should be altitude 3,658m or less.
• The humidity of the machine room should be 95% or less.
2.2 Location of the Control Panel
• Do not install the control panel where there is a vibration.
• Do not install the control panel where there is a dangerous material.
• Control panel should have the gap of minimum of 1m from obstacles or walls to secure minimum
space for installation adjustment work. [Figure 2.1]
• Install the control panel apart from windows so that it is not affected by temperature, wind direction,
or water.
• Install the control panel where there is little influence of RF (Radio Frequency).
