A
.
INSTALLATION MANUAL
FOR ELECTRICAL PARTS
3.2.2 Low Speed Test Drive
During the installation work, for low speed operation, a separate installation remote controller JIG is used,
and installation remote controller JIG is composed of Control Panel side remote controller JIG, CAR side
remote controller JIG, and installation remote controller. (Purchased and equipped by the installation
company)
REFER TO DRAWING NO. HE000525 INSTALL REMOTE.
1) Jumper Connector Work
Use the jumper connector enclosed in CONTROL PANEL such as safety circuit, door circuit, hoist way
limit switch, safety switch, etc. to have jumper work on the SAF board to prepare for the low speed
operation.
REFER TO DRAWING NO. 20400532 INSTALL CABLE.
2) How to Test Low Speed Drive
Low speed operation using T-Cable and hoist way pit cable installation remote controller JIG.
① Set the automatic/manual switch in the control panel to manual position.
② Insert UP/DOWN button contact point into the control panel CN-A1connector as a low speed
operation method using installation remote controller.
③ Connect remote controller E-STOP contact point into the enclosed jumper connector CN_R.
During the installation low speed operation, do not insert CAN communication
line into MAIN Board CM10 and CM11 in order to prevent CAN parts damage
Insert the connector after turning the power OFF in order to prevent CAN parts
damage, If CAN communication line connector CM10 and CM11 connections
are required.
