INSTALLATION MANUAL
FOR ELECTRICAL PARTS
3.2.3 Check List for Low Speed Test Drive
• Check if the status of all connections and jumper cables and mechanical status are correct.
• Place the AUTO/INS switch in the control panel toward downside (INS) to make it a manual mode.
• Press E.STOP switch in the control panel to make cut off safety line.
• In normal condition, check and turn ON the power of the main power connector box.
Check if there is a missing part in the jumper worked parts.
Check if installation remote controller JIGs are correctly connected to installation remote controller,
T-cable, and SAF Board.
Check if the remote controller connection works are done.
After supplying the power, take special caution for the electric shock.
• Turn ON MAIN NFB located at the top left side of Control Panel.
• Check if proper voltages are on each AC power and DC110V, DC24V.
• Check if GS, DS, SA relays are energized in SAF board.
• Connect HHT to the Main board to activate “installation manual operation mode”.
[2]SYSTEM MENU → 1.FACTORY & FIELD → 2.FIELD MODE SET-UP menu
Select “MANUAL DRIVE"
• Set the data with HHT according to "Appendix B: Inverter Initial Start-Up Manual [For more
information, refer to WBVF motor drive unit [Inverter] Manual]".
• Press UP/DOWN button of the remote controller to check if the rotation direction of the main part
matches the UP direction, and if it is reverse, connect one pair among U, V, W reversely to match
the direction.
• Check the operation of the brake, and perform electric and mechanical adjustment on the brake.
(Appendix A: VCON board adjustment manual)
• Perform UP/DOWN operation at the top of CAR with the remote controller at the top of CAR.
• When working with equipment, Report and Repeat based on the car (e.x. Car
up, Car down repeatedly says)
