WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
43 / 98
5.4 How to Set Hall Indicator Device
1) CPI Installation and Connection
After attaching CPI box to the CAR, precisely connect the sticking out CPI cable to CTC Board CN_T12
connector.
For CPI with DIP switches, turn all DIP switches to OFF or ON state to use it only for indication.
Cable Name
Starting Point
Destination Point
CPI cable (D1)
CPI
CH1
CTC
CN_T12
5.5 Other Matters for Setting
5.5.1 Voice Synthesis Device Speaker Volume Adjustment
Use COP-30D board VR1.
5.5.2 Cautions during the Replacement of COP-30D Board
When you replace COP-30D board, perform by the following order.
① Turn OFF CONTROL PANEL main power blocker NFB1 to turn off the CAR DC24V power, and
perform the work.
Do not take out or install a board while the power is supplied, it may cause
damage
② CAR buttons are inserted in sequence from the lowest floor CU1, and the cable colors are different
for each floor, so distinguish by this characteristic when the connector is taken out and inserted
again.
③ Insert Door Open button to CU64 (DOB) and Door Close button to CU63 (DCB).
④ When you replace COP-30D board, match the jumper pin settings with the previous COP-30D
board.
