Hyundai Elevator WBVF - Cautions During the Connections between CAN Communication Boards

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
40 / 98
5.3.2 Cautions during the Connections between CAN Communication Boards
1) End jumper
For smooth CAN communication, end resistor should be attached to the first and end part of CAN bus.
Therefore, there is a jumper (end jumper) in CTC board (CAR Top Control Board) to be able to turn
ON/OFF the end resistor.
If the end jumper is incorrectly set, CAN communication error may occur.
2) ID setting
COP
Classification
COP-30D board
SW1 NO.1
COP
Classification
WCOP30 board
SW1
Main
OFF
Expansion of the number of floors
for Main COP 31 floors or more
2 ON
Sub
(Penetration type Rear)
ON
Handicapped COP
ALL OFF
* After changing ID setting, the power of the board should be turned OFF ->ON for recognition.
<During the cabling between Handicapped COP, SUB COP, and main COP>
• Connect 『CAN communication cable』“C1” taken out from the Handicapped
COP and『CAN communication cable』“C2" taken out from SUB COP to the
main COP.
Wire the cable through bottom of the CAR, NOT THROUGH TOP OF THE CAR
