Hyundai Elevator WBVF - Connector Names

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
52 / 98
6.4.2 Connector Names
CN
Item
Description
Remark
UCPW
UCMP Board power
DC 24V
Figure 6.4①
ICE
Program downloading connector
Figure 6.4②
UCIN1
MNT, SS, RST Signal
MNT : Monitoring Relay
SS : SSA, SSB Status
ER_RST : Clear error
Figure 6.4③
UCIN2
For Door zone sensor signal
Figure 6.4④
UCIN3
Door switch signal
Car door, landing door
Figure 6.4⑤
UCSS
For safety line
Figure 6.4⑥
MNT
Monitoring relay
Figure 6.4⑦
DZA
Door zone signal relay 1
/w DZA LED
Figure 6.4⑧
DZB
Door zone signal relay 2
/w DZB LED
Figure 6.4⑨
CDR
Car door signal relay
/W CDR LED
Figure 6.4⑩
LDR
Landing door signal relay
/W LDR LED
Figure 6.4⑪
SSA
Safety relay 1
Figure 6.4⑫
SSB
Safety relay 2
Figure 6.4⑬
ER_RESET
S/W
Clear UCM error
/w ER_LED
Figure 6.4⑭
WDT LED
WATCH DOG LED
Figure 6.4⑮
Governor site connection is performed at TBMB-1 and TBMB-2 terminal block.
