Hyundai Elevator WBVF - Page 41

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
41 / 98
Reference 1) COP Combination Inside the CAR (30 floors or less)
COP B'd Combination (Under 30 Floors)
Number
Precondition
(MAIN COP)
[SIG. INPUT : CN_C1]
Selection 1
(SUB COP)
Selection 2
(WCOP1)
Selection 3
(WCOP2)
Combination 1
(MAIN +
Disabled 1)
MAIN (=MAIN COP)
(GOOD : COP-30D B'd)
WCOP1 (=Disabled COP
1)
(GOOD : WCOP30 B'd)
Connection
CN_C6 (→ WCOP1
CN_W1)
CN_W1 (→ MAIN
CN_C6)
SW1
SW1.ALL OFF
SW1.ALL OFF
Combination 2
(MAIN + SUB +
Disabled 1)
MAIN (=MAIN COP)
(GOOD : COP-30D B'd)
SUB (=SUB COP)
(GOOD : COP-30D B'd)
WCOP1 (=Disabled COP
1)
(GOOD : WCOP30 B'd)
Connection
CN_C10 (→ SUB
CN_C10)
CN_C6 (→ WCOP1
CN_W1)
CN_C10 (→ MAIN
CN_C10)
CN_W1 (→ MAIN
CN_C6)
SW1
SW1.ALL OFF
SW1.1 ON
SW1.ALL OFF
Combination 3
(MAIN + SUB)
MAIN (=MAIN COP)
(GOOD : COP-30D B'd)
SUB (=SUB COP)
(GOOD : COP-30D B'd)
Connection
CN_C10 (→ SUB
CN_C10)
CN_C10 (→ MAIN
CN_C10)
SW1
SW1.ALL OFF
SW1.1 ON
COMBINATION
4
(MAIN +
Disabled 1 +
Disabled 2)
MAIN (=MAIN COP)
(GOOD : COP-30D B'd)
WCOP1 (=Disabled COP
1)
(GOOD : WCOP30 B'd)
WCOP2
(=Disabled COP 2)
(GOOD : WCOP30 B'd)
Connection
CN_C6 (→ WCOP1
CN_W1)
CN_C7 (→ WCOP2
CN_W1)
CN_W1 (→ MAIN
CN_C6)
CN_W1
(→ MAIN CN_C7)
SW1
SW1.ALL OFF
SW1.ALL OFF
SW1.1 ON
