Hyundai Elevator WBVF - Page 71

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
71 / 98
2. VCON Board Connection
The connector names and the connection diagram of VCON board in [Figure A.1 VCON Board
Composition] are the same as [Table A.2 VCON Board Connector], [Figure A.2 VCON Board Brake
Voltage Connection Diagram], and [Figure A.3 VCON Board Safety Line Voltage Connection
Diagram].
Connector
Name
Pin Name
Function
Connection
CN_V1
A220B
Brake voltage board input
TR1 A220 [Vac] connection
B220
TR1 B220 [Vac] connection
P24
Voltage input for the operation of
RE1 (power relay)
MC2 Pin no.14 connection
DBKB
Main board DBKB connection
CN_V2
P160
Brake voltage output
BKA Pin no.1 connection
N160
BKA Pin no.3 connection
CN_V3
A85B
Input voltage to generate DC 110V
voltage
TR1 A85 [Vac] connection
B85
TR1 B85 [Vac] connection
CN_V4
P110
DC 110V output voltage
NPR connection
N110
SAF board CN_S11-4 connection
N110
GND connection
[Table A.2 VCON Board Connector]
