WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
33 / 98
Devices
Connectors
Remark
Safety switch
CC5
Emergency exit switch
CC8
Compen chain switch
CC6
Jumper if not applied
Gate switch 1
CC4
Gate switch 2
CC4B
Jumper if not applied
Safety edge X 1
CC25
Safety edge X 2
CC25B
Jumper if not applied
Safety lay power
CC23, CC23B
Safety lay X 1
CC24
Jumper if not applied
Safety lay X 2
CC24B
Jumper if not applied
Multi beam
CC24B
Jumper if multi beam is applied
CC24
For multi beam
CC16
Multi-beam adapter
Landing sensor
CN_T3
Ventilation fan
CC17
Fluorescent light
CC18
CAN communication
CN_T9
COP
CN_T1
CAN communication(for CPI)
CN_T14
Door inverter power
CN_T2
Close limit S/W
CN8
Open limit S/W
CN7
UVW
CN12
Encoder
CN4
Speaker
CN_T31
Speaker volume adjustment signal
CC11
Emergency light power output
CC28
Emergency light power input
CC28B
Input Signal to Protect to be Jammed Finger
CN_T10
[Table 5.2 CAR Junction Box Connection Parts]
