424
Appendix
Appendix
I/O Parameters
No. Parameter name
Default value
(Reference)
Input
range
Unit Remarks
120 Network attribute 1 1H
0H to
FFFFFFFFH
Bits 0 to 3: CC-Link remote register area
Bits 4 to 11:
H/L byte swap selection (0: Do not swap, 1: Swap)
Network link error check timer value (10msec)
(Main application ver. 1.39 or later, F-ROM32bit
version only)
* The number of used ports and number of
occupied stations in I/O parameter Nos. 14 and
15 must match.
121 Network attribute 2 0
0H to
FFFFFFFFH
122 Network attribute 3 0
0H to
FFFFFFFFH
123 Network attribute 4 0H
0H to
FFFFFFFFH
Bits 0 to 3: Ethernet TCP/IP message communication
Selection whether to permit 0.0.0.0 (IP address of
connection destination can be ignored) as IP
address of connection destination on server
(0: Do not permit
1: Permit (not recommended
))
* Note: Number of clients that can be connected
simultaneously to one server port channel = 1
124 Network attribute 5 0H
0H to
FFFFFFFFH
Ethernet TCP/IP message communication attribute
Ethernet client/server type
(0: Not in use
1: Client (Automatic assignment of own port number)
(2: Client (Specification of own port number)
This setting is not recommended
because of device
limitations, such as an error generation when the port is
opened for approx. 10 minutes after disablement of close
response check due to a power failure at the connection
destination, etc.)
3: Server (Specification of own port number))
* Note: Number of clients that can be connected
simultaneously to one server port channel = 1
Bits 0 to 3: IAI protocol B/TCP (MANU mode)
* PC software can be connected only in the case
of a client.
Bits 4 to 7: IAI protocol B/TCP (AUTO mode)
* PC software can be connected only in the case
of a client.
Bits 8 to 11: Channel 31 opened to user
Bits 12 to 15: Channel 32 opened to user
Bits 16 to 19: Channel 33 opened to user
Bits 20 to 23: Channel 34 opened to user
* If the parameter settings for own port number, client/server
type, IP address of connection destination and port number of
connection destination do not match completely between the
IAI protocol B/TCP MANU and AUTO modes, the connection
will be cut off when the MANU/AUTO mode is switched.
125 Network attribute 6 31E32h
0H to
FFFFFFFFH
Bits 0 to 7: Module-initialization check timer setting when
Ethernet is used (100 msec)
Bits 8 to 15: Module-initialization check timer setting when
Ethernet is not used (100 msec)
Bits 16 to 23: Increment of “PC/TP reconnection delay at
software reset” when Ethernet is used (sec)
PC: PC software
TP: Teaching pendant
