461
Appendix
Appendix
Other Parameters
No. Parameter name
Default value
(Reference)
Input range Unit Remarks
46 Other setting bit pattern 1 2001H 0H to
FFFFFFFFH
Bits 0 to 3: Variable-value format type in response message to
real-number/variable query
(0: Big endian with four upper/lower binaryconverted
bytes reversed, 1: Big endian)
Bits 4 to 7: Decimal-place rounding selection for real-number
integer-variable assignment in LET/TRAN commands
(0: Do not round, 1: Round)
Bits 8 to 11: For future expansion
* Change strictly prohibited unless specified by the
manufacturer.
Bits 12 to 15: Selection of processing to be performed when
subroutine first step input condition is not specified
when TPCD command = 1
(0: Do not execute, 1: Execute, 2: Error)
Bits 16 to 19: For future expansion
Bits 20 to 23: Continuous recovery movement/operation
resumption timing type
(0: Resume operation after completion of continuous
recovery movement of all axes using the same
task (same as before),
1: Hold resumption of operation while any axis is
performing continuous recovery operation (This
does not mean the system will wait for completion
of continuous recovery movement.))
(Main application version 0.47 or later)
Bits 28 to 31: Data operation type upon occurrence of backup
RAM data assurance mark non-confirmation error
0: Do not clear the backup RAM data
1: Clear the backup RAM data
(Main application version 0.94 or later)
47 Other setting bit pattern 2 0H 0H to
FFFFFFFFH
Bits 0 to 7: System Reservation
Bits 8 to 11: Whether to use servo monitoring IO monitor function
(0: Not to use, 1: Use)
(XSEL-P/Q/PCT/QCT main application Ver. 1.15 or later)
Bits 12 to 31: For expansion
48 (For expansion) 0
