Rev AA Using the Tools Page 4-5
• Print Darkness: The amount of energy being transferred into the
printhead. It should be set
to the lowest
value that provides acceptable
quality of print at the
required throughput.
• Interleaved Images: Enables a lower quality draft mode
of printing
with a 50% saving in ribbon consumption
•
Printhead Resistance: Matches the drive electronics of the printer
to
the resistance characteristics of the
printhead.
Printhead Setting in Continuous Mode
Touch the Printhead button on the setup page to access the printhead
parameters.
The Printhead page in continuous mode allows you to access the
following parameters:
• Print Position: Changes the angle of the printhead against
the target
material. This angle affects
the print quality. If the angle is not
suitable,
the resulting print may appear faded.
Note: Other parameters are same as intermittent mode.
Figure 4-5: Printhead Parameters in Continuous Mode
ICE Pegasus Service Manual
