14
3
BASIC OPERATION
3-5 Setting a band and frequency
Å SETTING AN OPERATING BAND
The transceiver has a triple band stacking register.This
means that the last 3 operating frequencies and
modes used on a particular band are automatically
memorized.
See the table below for a list of the bands available and
the default settings for each register.
■ USING THE BAND STACKING REGISTERS
[EXAMPLE]: 21 MHz band
➀ Push [21¶], then select a frequency and an operat-
ing mode.
• Frequency and operating mode are memorized in the
first band stacking register.
➁ Push [21¶] again, then select another frequency
and operating mode.
• This frequency and operating mode are memorized in
the second band stacking register.
➂ Push [21¶] again, then select another frequency
and operating mode.
• This frequency and operating mode are memorized in
the third band stacking register.
• When a fourth frequency and operating mode are se-
lected on a band, the first register is overwritten.
BAND REGISTER 1 REGISTER 2 REGISTER 3
1.9 MHz 1.900000 CW 1.910000 CW 1.915000 CW
3.5 MHz 3.550000 LSB 3.560000 CW 3.580000 LSB
7 MHz 7.050000 LSB 7.060000 CW 7.020000 CW
10 MHz 10.120000 CW 10.130000 CW 10.140000 CW
14 MHz 14.100000 USB 14.200000 USB 14.050000 CW
18 MHz 18.100000 USB 18.130000 USB 18.150000 USB
21 MHz 21.200000 USB 21.300000 USB 21.050000 CW
24 MHz 24.950000 USB 24.980000 USB 24.900000 CW
28 MHz 28.500000 USB 29.500000 USB 28.100000 CW
50 MHz 50.100000 USB 50.200000 USB 51.100000 FM
145 MHz 145.000000 USB 145.100000 FM 145.200000 FM
General 15.000000 USB 15.100000 USB 15.200000 USB
