Page #51 background image
49
7
MEMORY CHANNELS
7-1
General
7-2 Memory channel selection
[V/M] [M-CH]
CH
SWR
ALC
Po
S
1
20 50
3
3211.5
579 20 40 60
100%
MEMO
BLANK
CH
ANT
USB
SWR
ALC
Po
S
1
20 50
3
3211.5
579 20 40 60
100%
1
VFOA
Disappears when a channel is programmed
ANT
1
CW
VFO mode is selected
M-CH 2 is selected in VFO, then memory mode is
selected
The transceiver has 101 memory channels (plus 1 call
channel). Memory mode is useful for quickly changing
often-used frequencies.
All 101 memory channels are tuneable, which means
the programmed frequency can be tuned temporarily
with the tuning dial in memory mode.
Å IN VFO MODE
Push [V/M] to select VFO mode, if necessary, then
rotate [M-CH] to select a memory channel number.
All memory channels including blank channels can be
selected.
•“BLANK appears when no information has been pro-
grammed into a memory channel.
Push [V/M] to select memory mode.
•“MEMO and the contents of the memory channel ap-
pear.
MEMORY
CHANNEL
Regular
(split memory)
Scan edges
Call channel
TRANSFER
TO VFO
OVER-
WRITING
CLEAR
CAPABILITY
MEMORY
CHANNEL
NUMBER
Independent transmit and receive
frequencies and one mode in each
memory channel.
In addition, tone frequencies (or 1750
Hz tone burst) can also be stored for
repeater use.
One frequency and one mode in
each memory channel as scan edges
for programmed scan.
Same as regular.
199
Yes Yes Yes
No Yes No
Yes Yes NoP1, P2
C
