Icom IC-746 Instruction Manual

23
4
USING DIFFERENT OPERATING MODES
M1M2M3M4 -1
F1
F2
F3 F4 F5
F2
F3 F4 F5
SNDEDT001SET
KEY
F1
F2
F3 F4 F5
001
SND
50%
SideToneLevel
SET
F1
F2
Normal
NumberStyle
001
F1
F2
F1
F2
F3 F4 F5
EDT
M1
DELSPC
CQTESTCQTEST
F5
F4
F3
BLANK
1
4
CH
VFOA
ANT
AGCAMP
P.
SWR
ALC
Po
S
1
20 50
3
3211.5
579 20 40 60
100%
NAR
1
1
F
CW
M1
AGCDUP1/4KEYSCP
Memory keyer menu
Keyer set (SET) menu
Contest number (001) menu
Edit (EDT) menu
Transmit (SND) menu
Ç ELECTRONIC KEYER FUNCTIONS
The transceiver has a number of convenient functions
for the electronic keyer that can be accessed from the
memory keyer menu.
➀ Push [CW/RTTY] to select CW mode.
➁ Push [MENU] to select M1.
➂ Push [F4] to select the memory keyer menu.
➃ Push one of the multi-function keys ([F1] to [F5]) to
select an item in the memory keyer menu. See the
diagram below.
(1) Memory keyer settings menu
■ IN CW MODE

Icom IC-746 Specifications

General

Mode	SSB, CW, RTTY, AM, FM
Receiver Type	Double conversion superheterodyne
Antenna Connector	SO-239
Voltage	13.8 V DC ±15%
Impedance	50 ohms
Output Power	100 W (SSB, CW, FM, RTTY), 40 W (AM)
Current Drain	TX: 20 A
Sensitivity	AM: 2 µV
Selectivity	CW: 500 Hz (-6 dB)
