64
10
SET MODE
SET
MICU/DSpeed
HIGH
SET
CI-VBaudRate
Auto
SET
CI-VAddress
56h
SET
CI-VTransceive
ON
SET
CI-V731Mode
OFF
26. MIC U/D Speed
This item sets the rate at which frequencies are
scanned when the microphone [UP]/[DN] switches
are pushed and held. High or low can be selected.
27. CI-V Baud Rate
This item sets the data transfer rate. 300, 1200, 4800
9600, 19200 bps and AUTO are available.
When AUTO is selected, the baud rate is automati-
cally set according to the connected controller or re-
mote controller.
28. CI-V Address
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-746s is 56h.
When 2 or more IC-746s are connected to an op-
tional CT-17
LEVEL CONVERTER
, rotate the tuning dial
to select a different address for each IC-746 in the
range 01h to 7Fh.
29. CI-V Transceive
Transceive operation is possible with the IC-746 con-
nected to other Icom HF transceivers or receivers.
When ON is selected, changing the frequency, op-
erating mode, etc. on the IC-746 automatically
changes those of connected transceivers (or re-
ceivers) and vice versa.
30. CI-V with 731
When connecting the IC-746 to the IC-735 for trans-
ceive operation, you must change the operating fre-
quency data length to 4 bytes.
This item must be set to ON only when operating trans-
ceive with the IC-735.

Table of Contents
