40
3. ADVANCED SCOPE OPERATION
Waveform Color (Current)
Set the waveform color for the currently received
signals.
L
to adjust the
ratio from 0 to 255.
L The color is displayed in the box above the RGB
scale.
Waveform Color (Line)
Set the waveform outline color for the currently
received signals.
L
to adjust the
ratio from 0 to 255.
L The color is displayed in the box above the RGB
scale.
Waveform Color (Max Hold)
Set the waveform color for the received signals
maximum level.
L
to adjust the
ratio from 0 to 255.
L The color is displayed in the box above the RGB
scale.
Waterfall Display
Turn the Water fall display ON or OFF for the normal
scope or Mini scope screens.
L On the Expanded scope screen, the Waterfall is
always displayed.
• OFF: Turns OFF the Waterfall display.
• ON: Turns ON the Waterfall display.
Waterfall Speed
Select the Waterfall speed.
• Slow: Sets the waterfall speed to Slow.
• Mid: Sets the waterfall speed to Mid.
• Fast: Sets the waterfall speed to Fast.
Waterfall Size (Expand Screen)
Select the Waterfall height in the Expand scope screen.
• Small: The same height as the Normal scope
screen, only the FFT scope expands.
• Mid: The Waterfall height expands at the same
ratio as the FFT scope.
• Large: Only the Waterfall height expands.
Waterfall Peak Color Level
Select the signal level that the Waterfall displays a
peak color.
Higher signal levels are Red, Yellow, Green, Light-
blue, Blue and Black, in that order.
• Selection: Grid 1 ~ Grid 10
Waterfall Marker Auto-hide
Set the Waterfall Marker Auto-hide function to ON or
OFF.
• OFF: The marker in the Waterfall zone stays ON.
• ON: The marker in the Waterfall zone is hidden
2 seconds after it is in place.
Dual Scope Type
When the Dual scope is selected, select the Main and
Sub scope layout.
• Over/Under: Displays the Main scope over the
Sub scope.
• Side by Side: Displays the Main and Sub scopes
side by side.
Dual Scope Auto Select
When the Dual scope is selected, by selecting the
Main or Sub scope.
• OFF: The Main scope and Sub scope are not
switched by selecting the Main band or Sub
band.
• ON: The Main scope and Sub scope are
switched by selecting the Main band or Sub
band.
Continued on the next page
