3. ADVANCED SCOPE OPERATION
Fixed Edges
0.03 – 1.60
Set the Upper and Lower Edge frequencies for the
Fixed mode. Three edges are assigned to each band.
• Settable
range: 0.030 ~ 1.600 MHz
1.60 – 2.00
• Settable range: 1.600 ~ 2.000 MHz
2.00 – 6.00
• Settable range: 2.000 ~ 6.000 MHz
6.00 – 8.00
8.00 – 11.00
11.00 – 15.00
• Settable range: 11.000 ~ 15.000 MHz
15.00 – 20.00
• Settable range: 15.000 ~ 20.000 MHz
20.00 – 22.00
• Settable range: 20.000 ~ 22.000 MHz
22.00 – 26.00
• Settable range: 22.000 ~ 26.000 MHz
26.00 – 30.00
• Settable range: 26.000 ~ 30.000 MHz
30.00 – 45.00
• Settable range: 30.000 ~ 45.000 MHz
45.00 – 60.00
• Settable range: 45.000 ~ 60.000 MHz
L Touch
to select the upper and lower edge
frequency, and then rotate
or touch the key
pad to edit the frequency.
