IDS uEye series User Manual

© 2009 IDS Imaging Development Systems GmbH126
User Manual uEye Cameras V3.32
UI-155x / UI-555x
Sensor specification
Sensor type
CMOS
Shutter system
Electronic rolling shutter
Readout mode
Progressive scan
Resolution class
UXGA
Resolution
1600 x 1200 pixels (1.92 Mpixels)
Aspect ratio
4:3
Bit depth
10 bits
Optical sensor class
1/3 inch
Exact sensitive area
4.48 x 3.36 mm
Exact optical sensor diagonal
5.6 mm (1/2.9 inch)
Pixel size
2.8 µm, square
Sensor name, monochrome
-
Sensor name, color
Micron MT9D131
Gain
Color model (master/RGB)
3.5x/3.1x
Offset control, mode
Auto/manual, additive
Gain boost
2.0x
Camera timing
USB uEye
GigE uEye SE
GigE uEye HE
Pixel clock range
MHz
5-43
*1)
3-45
*1)
3-60
*1)
Pixel clock range (with subsampling/binning)
MHz
5-50
*1)
3-55
*1)
3-60
*1)
Frame rate (freerun mode)
fps
18
*2)
19
*2)
25
*2)
Frame rate (trigger mode, 1 ms exposure)
fps
17
*2)
16.5
*2)
23
*2)
Exposure time in freerun mode
ms
0.038 *
2)
- 12.8s
*3)
0.036 *
2)
- 21.4s
*3)
0.027 *
2)
- 21.4s
*3)
Exposure time in trigger mode
ms
0.038 *
2)
- 12.8s
*3)
0.036 *
2)
- 21.4s
*3)
0.027 *
2)
- 21.4s
*3)
AOI
Mode
Horizontal
*4)
+ Vertical
*4)
AOI image width, step width
Pixels
32 - 1600, 4
32 - 1600, 4
32 - 1600, 4
AOI image height, step width
Pixels
4 - 1200, 2
4 - 1200, 2
4 - 1200, 2
AOI position grid horizontal, vertical
Pixels
4, 2
4, 2
4, 2
AOI frame rate, 1280 x 1024 pixels (SXGA)
fps
35
37
49
AOI frame rate, 1024 x 768 pixels (XGA)
fps
40
42
56
AOI frame rate, 640 x 480 pixels (VGA)
fps
88
92
122
Binning
Mode
Horizontal
*4)
+ Vertical
*4)
Method
H + V: Color binning, averaging
Frame rate with 2x binning, 800 x 600 pixels
fps
60
60
73

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
