User Manual uEye Cameras V3.32
Notes on using the UI-155x / UI-555x
· At very long exposure times and minimum gain, the white level may not be reached.
Increase the gain by one step.
· For AOI width <160 pixels, the sensor gets slower.
· Horizontal and vertical binning can only be used together.
· The sensor binning works by averaging pixels, so the image will not become brighter
when binning is activated.
· Homogeneous images may show color aberrations in the corner areas. This is
caused by the way the micro lenses are placed on this sensor. The effect can be
minimized by using a large aperture on the lens (small F number).

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
