IDS uEye series User Manual

© 2009 IDS Imaging Development Systems GmbH130
User Manual uEye Cameras V3.32
Frame rate with 3x binning, 680 x 512 pixels
fps
56
50
56
Frame rate with 4x binning, 512 x 384 pixels
fps
73
71
73
Frame rate with 6x binning, 340 x 256 pixels
fps
106
104
106
Subsampling
Mode
Horizontal
*4)
+ Vertical
*4)
Method
H + V: Color subsampling
Frame rate w/ 2x subsampling, 1024 x 768
pixels
fps
44
44
52
Frame rate with 3x subsampling, 680 x 512
pixels
fps
97
92
101
Frame rate w/ 4x subsampling, 512 x 384
pixels
fps
160
153
156
Frame rate w/ 5x subsampling, 408 x 306
pixels
fps
220
217
220
Frame rate with 6x subsampling, 340 x 256
pixels
fps
283
280
283
Frame rate w/ 8x subsampling, 256 x 192
pixels
fps
410
407
410
Hardware trigger
Mode
Asynchronous
Asynchronous
Asynchronous
Trigger delay with rising edge
µs
19.7 ±0.25
< 5
< 5
Trigger delay with falling edge
µs
38.0 ±0.25
< 5
< 5
Additive trigger delay (optional)
µs
15 µs-4 s
15 µs-4 s
15 µs-4 s
Sensor delay to exposure start
µs
< 200
*2)
< 200
*2)
< 200
*2)
Connected load
*5)
USB uEye
GigE uEye SE
GigE uEye HE
W
0.4-0.7
2.4-2.9
2.8-3.9
*1)
The maximum possible pixel clock frequency depends on the PC hardw are used.
*2)
Requires maximum pixel clock frequency.
*3)
Requires minimum pixel clock frequency.
*4)
Use of this function increases the frame rate.
*5)
The connected load depends on the sensor model and the pixel clock setting.

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
