IDS uEye series User Manual

© 2009 IDS Imaging Development Systems GmbH132
User Manual uEye Cameras V3.32
UI-148x / UI-548x
Sensor specification
Sensor type
CMOS
Shutter system
Electronic rolling shutter / global start shutter
Readout mode
Progressive scan
Resolution class
QSXGA
Resolution
2560 x 1920 pixels (4.92 MP)
Aspect ratio
4:3
Bit depth
10 bits
Optical sensor class
1/2 inch
Exact sensitive area
5.63 x 4.22 mm
Exact optical sensor diagonal
7.0 mm (1/2.3 inch)
Pixel size
2.2 µm, square
Sensor name, monochrome
Micron MT9P031
Sensor name, color
Micron MT9P031
Gain
Monochrome model (master gain)
30.0x
Color model (master/RGB)
12.0x/6.5x
Offset control, mode
Auto/manual, additive
Gain boost
1.6x (color model only)
Camera timing
USB uEye
GigE uEye SE
GigE uEye HE
Pixel clock range
MHz
5-43
*1)
4-48
*1)
4-103
*1)
Pixel clock range (with subsampling/binning)
MHz
5-90
*1)
4-100
*1)
4-128
*1)
Frame rate (freerun mode)
fps
6.3
*2)
7.04
*2)
15
*2)
Frame rate (trigger mode, 1 ms exposure)
fps
6.1
*2)
6.57
*2)
13.8
*2)
Exposure time in freerun mode
ms
0.075 *
2)
- 2745
*3)
0.067 *
2)
- 3430
*3)
0.031 *
2)
-3430
*3)
Exposure time in trigger mode
ms
0.075 *
2)
- 2745
*3)
0.067 *
2)
- 3430
*3)
0.031 *
2)
-3430
*3)
AOI
Mode
Horizontal
*4)
+ Vertical
*4)
AOI image width, step width
Pixels
32 - 2560, 4
32 - 2560, 4
32 - 2560, 4
AOI image height, step width
Pixels
4 - 1920, 2
4 - 1920, 2
4 - 1920, 2
AOI position grid horizontal, vertical
Pixels
4, 2
4, 2
4, 2
AOI frame rate, 1920 x 1080 pixels (HD 1080)
fps
13
15
32
AOI frame rate, 1024 x 768 pixels (XGA)
fps
27
30
65
AOI frame rate, 640 x 480 pixels (VGA)
fps
52
58
126
Binning
Mode
Horizontal
*4)
+ Vertical
*4)
Method
H + V: Color binning, H: additive, V: averaging

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
